If the jumper setting is 'HI-speed Data' (JP2003 jumpered), this port is usable for 9600 bps DATA communications, because the filter and limiter are not engaged in the Audio line. Output level 200 mV/600 Ohms If the Jumper setting is 'Low-speed Data' (JP2004 jumpered), this port is usable in the AUDIO (300~3000 Hz) range. Output level 600 mV/10k Ohms RX Low-speed Data Output Type (jumper JP2004).
Vertex vx 3200 programming software manual#
Ignition 13.8V Pin 16: NC A IN CCESSORY DSUB 25-Pin Operating Manual Reprint C ONNECTOR Pin 17: RX DO RX Hi-speed Data Output Type (jumper JP2003).
This feature is only enabled on transceivers con- figured for Dual Deck operation. Via programming by your VERTEX STANDARD dealer.
Vertex vx 3200 programming software series#
View and Download Vertex Standard VX-3200 Series operating manual online. Maximum current is 20 mA.Ĭurrent list of Vertex/Standard Radio programming files available for download in the members area. Maximum output current is 200 mA Pin 15: IGN The VX-5500 may automatically be switched to the STAND-BY mode when the vehicle's igni-tion key is turned on. Switched and regulated DC 5.0V output for supplying power to an accessory (jumper JP2007). Pin 14: DC OUT Switched 13.8V output for supplying power to an accessory (jumper JP2008). If the jumper setting is 'HI-speed Data' (JP2005 jumpered), this port is usable for 9600 bps DATA communications, because the filter and limiter are not engaged in the Audio line. Input level 40 mV/600-Ohms If the Jumper setting is 'Low-speed Data' (JP2006 jumpered), this port is usable in the AUDIO (300~3000 Hz) range. Input level 800 mV/600 Ohms, Max.input 1.2V Tx Low-speed Data input Type ( Jumper JP2006). DSUB 25-P Pin 13: TXDI TX Hi-speed Data Input Type (jumper JP2005). I found this info at: It's easier to read it there.
